YLMK-500 temperature control module

FOB Reference Price:Get Latest Price
5 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
YATAI
Model Number:
YLMK-500
Usage:
Indoor
Theory:
Temperature Controller
SupplyAbility
SupplyAbility:
10000 Piece/Pieces per Month
Packaging & Delivery
Port
SHANGHAI
Lead Time :
5-7 days upon remit

Specifications

The YLMK-500 series module developed by our company is PID temperature control mode, the whole unit adopts advanced technology..

General Description

The YLMK-500 series module developed by our company is PID temperature control mode, the whole unit adopts advanced technology such as hardware and software of electromagnetic compability design and surface mount process, the temperature control module series connect with main equipment through RS485 interface and MODBUS communication protocol, the main equipment can be computer, as well as human-computer interface. The communication protocol includes RTU mode and ASCII mode, open all the functions of module, and realize the setting up and reading of all the parameters. Especially suitable for temperature control circumtances such as extruder and sheet machine.

·For the transducer PT100: -60-400 degree; K: 0-1300 degree; E: 0-600 degree; J: 0-800 degree can be selected.

·Resolution ratio: 0.1 degree.

·Output: 240V/1A electric relay output/SSR output

·Communication interface: isolated RS485, baud rate can be selected.

·Communication protocol: MODBUS-RTU, MODBUS-ASCII

·Supply voltage: 85-264VAC/DC24V

Remark: The writing operation time of the module is 100 thousade times.
